BAKER 306L / LONG STYLUS LEVER TYPE DIAL GAUGE (0.002 MM L.C., 0.2 MM RANGE), WITH ACCESSORIES, 38 MM BEZEL DIA

BAKER 306L / LONG STYLUS LEVER TYPE DIAL GAUGE (0.002 MM L.C., 0.2 MM RANGE), WITH ACCESSORIES, 38 MM BEZEL DIA

306L / LONG STYLUS LEVER TYPE DIAL GAUGE (0.002 MM L.C., 0.2 MM RANGE), WITH ACCESSORIES, 38 MM BEZEL DIA

Lever Type Dial Gauges, Fixed with Jewels, rigid brass body, Metric & inch range. Dia.2mm tungsten carbide ball stylus. With 33.6 & 32.4 long stylus.

₹ 6,442.00
₹ 6,442.00 ₹ 8,366.00
Sale Sold out

Price inclusive of 18% GST (GST Amount 892.58)

Estimated Dispatch Time:

Download Catalog
View full details

Product Details

FEATURES:

  • Every gauge carries a calibration certificate giving actual values
  • Auto reversal mechanism
  • Fitted with jewels and Swiss miniature ball bearings for smoother operation
  • Robust and highly sensitive gauge suitable for workshop use
  • Metric Gauges conform to IS 11498 and for the European market to DIN 2270
  • Inch Gauges conform to ASME B89.1.10M
  • Special dial Gauges for OEMs also manufactured on request
  • Complete spares and after sales service available
  • Integral dovetail offers flexibility and rigidity for mounting of the gauge
  • Metric & Inch gauges are supplied with 2mm tungsten carbide ball stylus and 8 mm spigot assembly as standard supply
  • No additional accessories are offered when suffix A is added to the type number
