FEATURES:

• Specification: IS, DIN, ANSI & JIS
• Every gauge carries a calibration certificate giving actual values
• Auto reversal mechanism
• Fitted with jewels and Swiss miniature ball bearings for smoother operation
• Robust and highly sensitive gauge suitable for workshop use
• Metric Gauges conform to IS 11498 and for the European market to DIN 2270
• Inch Gauges conform to ASME B89.1.10M
• Special dial Gauges for OEMs also manufactured on request
• Complete spares and after sales service available
• Integral dovetail offers flexibility and rigidity for mounting of the gauge
• Metric & Inch gauges are supplied with 2 mm tungsten carbide ball stylus and 8 mm spigot assembly as standard supply
• No additional accessories are offered when suffix A is added to the type number
• Additional 1 mm carbide ball stylus, Height Gauge adaptor, spanner, universal clamp and 4 mm dovetail spigot assembly offered as additional accessories for gauges where type number is without suffix A
