Features:
Multi-mode with Pulse-Echo for thickness and Echo-Echo for through coating measurements.
A scan & B scan functions for in depth inspection of material properties.
Difference and reduction rate display.
Max, min and current values can be displayed simultaneously.
Selectable update rate.
Data storage and recall.

Applications:
Applicable to measure the thickness of many materials, like steel, cast iron, aluminium, red copper, brass, zinc, quartz glass, polyethylene, PVC, gray cast iron, nodular cast iron and other ultrasonic wave well-conductive materials.Having through coating measurement capability, it can used to measure concrete coating thickness  It is widely used in almost all kinds of industries.

Measuring principle:
Ultrasonic thickness gauge determines the sample thickness by measuring the amount of time it takes for a sound pulse, generated by an ultrasonic transducer, to travel through a test piece and reflect from the inside surface or a far wall.
